A closer look
Urtopia Carbon Fold 2 E-Bike
- Motor Power
- Rated Power 250W (Peak Power 470W) rear hub
- Battery
- 244.8Wh
- Pedal Assist Range
- Up to 39 miles,
- Total Payload Limit
- 220lbs
Get to know your ride.
- Material
- Carbon fiber frame & fork
- Brakes
- TEKTRO 2-piston Hydraulic disc brakes
- Wheels
- Kenda 18" x 2.0"
- Sensors
- Torque sensor
- Fork
- Carbon fiber fork
Every angle. Every possibility.
Take a closer look.
Manufacturer photos. Colors and equipment vary by configuration. Some photos show optional accessories, sold separately.
Know before you choose
Specifications & fit
General Info
- Ideal use
- Commuter
- Bike Weight
- 36.3 lbs (16.5kg)
- Net Weight
- 35.2lbs（16kg）w/battery / 30.8lbs (14kg) w/o battery / *All stated weight have tolerance <5%. Net weight excludes all accessories such as rack, kickstand, fender, pedals etc.
- Material
- Carbon fiber frame & fork
- Folding
- Yes
- Frame style
- Step-Over
- Pedal Assist Range
- Up to 39 miles, / Up to 84 miles with extender battery / *The range was tested with a 180 lb rider, riding in ECO mode on flat roads with pedal assist only and no throttle.
- Top Speed
- 20mph
- Total Payload Limit
- 220lbs
- Rider Height
- Regular: 5'1'' - 6'1''
- Brakes
- TEKTRO 2-piston Hydraulic disc brakes
- Wheels
- Kenda 18" x 2.0"
- Bike Water Resistance
- IP65
Ebike System
- Motor Power
- Rated Power 250W (Peak Power 470W) rear hub
- Motor Max. Torque
- 26Nm
- Battery
- 36V 6.8Ah (244.8Wh) Seat Post Battery, UL 2271 & EN 50604 Certified
- External Battery
- 36V 9.8Ah (352.8Wh) Optional external battery
- Pedal Assist
- 4 levels
- Charger
- 36V 2A Charger, DC Head, 4 Hour Charging Time / 36V 4A Fast Charger, 2-Hour Charging Time
- Display
- 2.0'' Color LCD display
- USB Charge
- Yes
- Sensors
- Torque sensor
- Lights
- Front: External headlights 30 lux / Rear: Integrated rear light
- Throttle
- Optional (up to 20 mph)
- Class
- Class 1 or 2
Drivetrain
- Chainrings
- 52T
- Crankset
- Aluminum, length 170mm
- Cassette
- 11-32T, 8 Speed
- Chain
- Shimano 8-Speed
- Rear Derailleur
- Shimano Altus 8-Speed
- Shift Lever
- 8 Speed Trigger
- Pedals
- Foldable PC pedals, 90x74x28mm
Cockpit
- Grips
- Durable ergonomic grips, lockable
- Seat Post
- Aluminum Alloy with In-Tube Battery, 46mm Clamp, / Adjustment Range: 150mm
- Fork
- Carbon fiber fork
- Saddle
- DDK Saddle, 263x165mm
- Handlebar
- Aluminum, 620mm Wide
- Stem
- Aluminum Folding Stem, Height & Angle Adjustable with Quick Release
Smartbar
- Smartbar features
- No
- Connectivity
- No
- App
- only for OTA
- SIM/Connect Service
- No
Size guide
One Size
- Recomm. rider height
- 5’1’’ - 6’1’’
- A. Adjustable seat range
- 150 mm (6’’)
- B. Highest point of the seat post
- 1030 mm (40’’)
- C. Overall length
- 1520 mm (60’’)
- D. Handlebar grips height
- 1130 mm (44.5’’)
- E. Headset height range
- 150 mm (6’’)
- F. Seat tube length
- 330 mm (13’’)
- G. Wheel diameter
- 450 mm (18’’)
- H. Wheelbase
- 1050 mm (41’’)
- I. Height after folding
- 690 mm (27’’)
- J. Overall length after folding
- 820 mm (32’’)
- K. Standover height
- 570 mm (22’’)
- L. Width after folding
- 480 mm (19’’)
Range figures are manufacturer estimates. Battery configuration, assist level, terrain, temperature, tire pressure, and rider or cargo weight affect actual distance. Optional extra batteries apply only when included in your selected configuration.
A little local advice
Your questions, answered.
How do I choose the right configuration?
Use the options beside the product price. For help with frame size, rider fit, or battery choice, call (609) 867-9792 or contact our Galloway shop.
How do I get my order?
Order online for pickup at Andy’s E-Bikes, 27 South New York Road, Galloway, NJ 08205. Contact our team to confirm pickup timing.
What affects battery range?
Published range is a manufacturer estimate. Your battery configuration, assist level, hills, speed, temperature, and rider or cargo weight all affect distance. Optional range-extender figures apply only with that battery fitted.
Manufacturer information & resources
Model-specific reference information. Follow the manufacturer’s instructions for setup, use, and care.
- newurtopia.com — urtopia carbon fold 2 ebike · Checked 2026-09-19
