A closer look
Velotric T1 Ebike
- Motor Hub
- 350W, Peak 600W, 45Nm
- Battery
- 352.8Wh
- Max Range
- Up to 70 miles
- Max Bike Load
- 330lbs

Get to know your ride.
- Fork
- 6061 Aluminum Alloy, Internal Brake Routing, 12x100mm Thru-axle, 1-1/4” to 1-1/8” Tapered Steerer, Fenders Compatible
- Sensor
- 2-Side Torque sensor
- Brake
- TEKTRO HD-R280 Hydraulic Disc Brake
- Tire
- 700x38c Ebike Puncture Resistant Tires
Every angle. Every possibility.
Take a closer look.
Manufacturer photos. Colors and equipment vary by configuration. Some photos show optional accessories, sold separately.
Know before you choose
Specifications & fit
Frameset Plus
- Frame
- 6061 Triple-Butted Aluminum Alloy Frame, Integrated Cable Routing, Internal Battery, Flat Mount Disc, Rack and Fenders Compatible
- Fork
- 6061 Aluminum Alloy, Internal Brake Routing, 12x100mm Thru-axle, 1-1/4” to 1-1/8” Tapered Steerer, Fenders Compatible
Electronics Plus
- Motor Hub
- 350W, Peak 600W, 45Nm
- Battery
- 36V, 9.8Ah, 352.8Wh
- Cell
- Samsung 21700
- Charger
- 36V, 2.0A, Operates on 100V-240V AC, 50-60Hz
- Charging Time
- 0-80% 4 Hours, 0-100% 6 Hours
- Sensor
- 2-Side Torque sensor
- Control Panel
- Fingerprint Unlock, Automatic Rider Recognition, Battery Indicator, PAS Indicator, Auto Headlight, Auto Brightness Control
- Security
- Theft Alert, GPS-Tracking, Fingerprint and Bluetooth Unlock
- Headlight
- Light Sensing, 6v/3w/45Lux High-Output Integrated LED, Adjustable Angle
- Pedal Assist
- Eco, Tour, Normal, Sport and Turbo Pedal Assist
- Walk Mode
- 2.9 MPH
- Water Resistant
- IPX6
Speed & Range Plus
- Max Speed
- 20 MPH, Class 1
- Default Speed (Unlock)
- 25 MPH
- Max Range
- Up to 70 miles
- Chainrings
- PROWHEEL Pro Aluminum Alloy, 40T Narrow Wide Chainring
- Crankset
- Aluminum Alloy, 170mm
- Cassette
- SHIMANO 8 Speeds, 12-32T
- Rear Derailleur
- SHIMANO M310-8
- Shift Lever
- SHIMANO M315-8
- Chain
- KMC Z8.3
Accessories Section Plus
- Fenders
- Supported, buy separately from VELOTRIC
- Rear Rack
- Supported, buy separately from VELOTRIC
- Range Extender
- 36V, 4.9Ah, 176.4Wh
Brake Plus
- Brake
- TEKTRO HD-R280 Hydraulic Disc Brake
- Rotors
- 160mm Front and Rear
- Brake Levers
- TEKTRO HD-R280 Aluminum Alloy, with adjustable reach
Wheel Plus
- Rims
- 700c Disc, Double-Wall Aluminum Alloy, Pinned (F) 24 Hole / (R) 28 Hole
- Front Hub
- NOVATEC Aluminum Alloy J-Hook Disc Hub,12x100mm Thru-Axle
- Tire
- 700x38c Ebike Puncture Resistant Tires
Cockpit Plus
- Handlebars
- 6061 Aluminum Alloy, Φ31.8mm, 680mm
- Grips
- VELOTRIC Sports Grips
- Stem
- 6061 Aluminum Alloy, 3D-Forged Alloy, 8-Degree Rise, 31.8mm Clamp, Garmin Mount Compatible
- Saddle
- SELLE ROYAL SRX
- Seat Post
- 6061 Aluminum Alloy, 30.9 x 300mm
Supports Plus
- Phone Mount
- Adapt GoPro/Garmin
- Pedals
- Aluminum Alloy
- Kickstand
- Aluminum Alloy
Weight & Load Plus
- Bike Weight
- 36lbs
- Max Bike Load
- 330lbs
Size guide
Medium
- Recommended rider height
- 5′6″–6′0″
- Seat tube length
- 480 mm
- Standover height
- 757 mm
- Saddle height
- 810–982 mm
Large
- Recommended rider height
- 5′10″–6′5″
- Seat tube length
- 525 mm
- Standover height
- 805 mm
- Saddle height
- 855–1025 mm
Range figures are manufacturer estimates. Battery configuration, assist level, terrain, temperature, tire pressure, and rider or cargo weight affect actual distance. Optional extra batteries apply only when included in your selected configuration.
A little local advice
Your questions, answered.
How do I choose the right configuration?
Use the options beside the product price. For help with frame size, rider fit, or battery choice, call (609) 300-0411 or contact our Galloway shop.
How do I get my order?
Order online for pickup at Andy’s E-Bikes, 27 South New York Road, Galloway, NJ 08205. Contact our team to confirm pickup timing.
What affects battery range?
Published range is a manufacturer estimate. Your battery configuration, assist level, hills, speed, temperature, and rider or cargo weight all affect distance. Optional range-extender figures apply only with that battery fitted.
